OVERVIEW
Suitable for solo travellers due to compact size.
Small, compact & light weight.
Combination shower & toilets.
Functional designs.
Towable by small to medium vehicles.
Available Length: 14′ – 17’6” Foot
Sleeps: 2-3 Adults
Weight: Ball 200kg | Tare 1760kg
Based on standard base models, and will fluctuate depending on your selected custom options.
OVERVIEW
Suitable for solo travellers due to compact size.
Small, compact & light weight.
Combination shower & toilets.
Functional designs.
Towable by small to medium vehicles.
Available Length: 14′ – 17’6” Foot
Sleeps: 2-3 Adults
Weight: Ball 200kg | Tare 1760kg
(Based on 15’8 Layout chosen)
MODEL OPTIONS
Compact Shower Toilet Model
Pop-Top Available
Queen or Single Beds
L Shape or Dinette Seating
MODEL OPTIONS
Compact Shower Toilet Model
Pop-Top Available
Queen or Single Beds
L Shape or Dinette Seating
TAKE OUR VIRTUAL TOUR
DESIGNED FOR COMFORT
Available in Queensize bed layout and Single Beds. Lightweight to tow around, easy to hook up and escape the rat race. Roomy enough to be comfortable, packed full of all the creature comforts you love, this model has already made a big impression with its very clever designed layout.
DESIGNED FOR COMFORT
Available in Queensize bed layout and Single Beds. Lightweight to tow around, easy to hook up and escape the rat race. Roomy enough to be comfortable, packed full of all the creature comforts you love, this model has already made a big impression with its very clever designed layout.
SPECIFICATIONS
- Size range : 14′ – 17’6”
- Family/Bunks : 2 or 3
- Ensuite : Combination
- Lounge type available : Café, L-shape
- Washing machine : Yes ( certain layouts only )
- Supa Gal Chassis Painted
- 4” ‘A’ Frame & Main Rails
- 2” Chassis Raiser
- 2.5T Torflex Rubber Torsion
- 15” 235/75/R15 A/T Wheels On Tandem Axle Caravans
- 2 X 95Lt Water Tanks
- 2 X 9Kg Gas Bottles & Holders On ‘A’ Frame
- Adjustable Corner Stabilizer Jacks To Front & Rear Of Caravan
- 1 X Spare Wheel
- 2 X Battery Boxes To Side Of Chassis
- Straight 3 Arm Bumper Bar
- 50mm Ball Coupling
- Led Lighting Throughout
- 1 X Roof Mounted Solar Panel
- 1 X Lead Acid Battery In Box On Chassis
- 2 Internal Roof Speakers
- 2 External Speakers
- External Picnic Table
- Led Running Lights
- 1 X Small Roof Hatch With Lights
- External Power Point
- Anderson Plug For Charging Battery
- Digital Display Battery Management System
- L Shaped Or Straight Seating
- 3 Way Aes Fridge
- Microwave
- Gas Electric Mini Grill – No Oven
- Small Stainless Steel Sink With Drainer
- Queen Innerspring Mattress
- Single Innerspring Mattresses – Some Models Only
- Roll Out Awning With Led Strip Light
- 12V Power Hatch Over Shower
- Ribbed Side Aluminium Cladding
- Composite Panel Front & Rear
- One Piece Fiberglass Roof
- Roof Mounted Reverse Cycle Air Conditioner
- Ducted Reverse Cycle Air Conditioner For Pop-Top Vans
- Checker Plate Wheel Spats
- Full Sheet Front Lower Checker Plate
- Full Sheet Rear Lower Checker Plate
- Side Checker Plate
- All Black 2RC Main Door With Security Mesh
- Gal Lined Front Tunnel Boot With Solid Access Doors
- Gas Electric Storage Hot Water System
- Fully Moulded Combo Shower/Toilet With Basin
- Cassette Toilet
- Lockable Water Fillers
- 12V Pump
- Gas Bayonet Point For B.B.Q
- Cold Tap On ‘A’ Frame
- Acrylic Flat Internal Doors
- Metal Full Extension Drawer Runners
- Fire Extinguisher, Fire Blanket & Smoke Detector
- 12V CD/DVD Player
- Lift Up Queen Bed – Some Models Only
- Side Drapes To All Windows
- Double Glassed Windows With Block Out & Fly Screen
- Laminate Bench Tops & Splash Backs
- Pleather Seating Upholstery
- Caravan Jacking System & Wheel Brace
- 12V Rangehood
- DSC Stability Control
- Break Away Brake System
- Pull Out Metal Pantry – Some Models
- Flick Mixer Taps Through Out
- Mains Pressure Inlet For Town Water
- Reverse Camera & Car Screen
- 1 Year Factory Warranty
- 3 Years Extended Warranty
- Upgrades – Contact Local Dealer
- Custom Build Options – Contact Local Dealer
- Battery Systems & Upgrades Available – Contact Local Dealer
- Semi-Outback Available: Yes
- Outback Available: Yes
- PopTop Available: Yes
- Single Beds option : Yes
- Full Customization : Yes
- Seating – Dinette, L Shaped
- Up To 16 Inch Wheels
- Diesel Heater
- 12V To 12V Redarc Charger
- Extend Length Of Van
- Stereo / DVD Upgrade
- Satellite / Foxtel System
- Wifi/ Charger
- Suspension – Semi Outback/ Outback – Independent.
- Extra Hatches / LED
- Dream Lighting Overhead Cupboards (CNC Models Only)
- Exterior LED Flood Flush Light
- CNC Designer Furniture
- Oven Upgrade
- Remove Curtains
- Add Pull Out Pantry
- Additional Solar Panels
- Slide Out BBQ (Not Webber Q)
- Inverter Or Solar Panels
- Change Or Alter Layout Design To Requirements
| MICRO RANGE | TARE WEIGHT | BALL WEIGHT | SHIPPING LENGTH | HEIGHT | WIDTH |
| M-10 | 2050 | 180 | 7500 | 2950 | 2450 |
| M-09 | 2000 | 150 | 7400 | 2950 | 2450 |
| M-08 | 2000 | 150 | 7400 | 2950 | 2450 |
| M-07 | 1900 | 200 | 7300 | 2950 | 2450 |
| M-06 | 1900 | 180 | 7300 | 2950 | 2450 |
| M-05 | 1850 | 190 | 7100 | 2950 | 2450 |
| M-04 | 1800 | 190 | 7000 | 2950 | 2450 |
| M-03 | 1800 | 190 | 7000 | 2950 | 2450 |
| M-02 | 1700 | 140 | 6500 | 2950 | 2450 |
| M-01 | 1700 | 165 | 6500 | 2950 | 2450 |
THE MICRO RANGE IS AVAILABLE IN A POP TOP RANGE FOR AN ADDITIONAL FEE. THE HEIGHT OF THIS RANGE AS A BASE MODEL INCLUDING ROOF ANTENNA & ROOF HATCH FOR SHOWER IS 2550MM WITH ROOF CLOSED.
Please note that all images, videos and virtual tours may not be reflective of standard base models, as some visuals showcase dealer added upgrades. Additionally, all models have options for custom colour selection.
